FT-24PGM370 48v Brushed dc Planetary Gear Reducer Motor
Product Video
| Reduction ratio | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 | 516 | |
| 6.0V | No-load speed(rpm) | 280 | 195 | 105 | 75 | 55 | 40 | 29 | 21 | 15 | 11 |
| Rated speed(rpm) | 250 | 180 | 95 | 68 | 48 | 35 | 25 | 18 | 12 | 9 | |
| Rated torque(kg.cm) | 0.3 | 0.5 | 0.7 | 1.0 | 1.4 | 2.0 | 2.5 | 3.5 | 4.4 | 5.0 | |
| 12.0V | No-loadspeed(rpm) | 280 | 195 | 105 | 75 | 55 | 40 | 29 | 21 | 15 | 11 |
| Rated speed(rpm) | 250 | 180 | 95 | 68 | 48 | 35 | 25 | 18 | 121 | 9 | |
| Rated torque(kg.cm) | 0.3 | 0.5 | 0.7 | 1.0 | 1.4 | 2.0 | 2.5 | 3.5 | 4.4 | 5.0 | |
Application
Planetary geared motors have the following characteristics:
1、High torque
2、Compact structure:
3、High precision
4、High efficiency
5、Low noise
6、Reliability:
7、Diversified choices
Generally speaking, planetary geared motors have the characteristics of high torque, compact structure, high precision, high efficiency, low noise and reliability, and are suitable for various mechanical transmission and motion control fields.
Application
DC Gear Motor Widely Used In Smart home appliances, Smart pet products ,Robots, Electronic locks, Public bicycle locks, Electric daily necessities, ATM machine , Electric glue guns, 3D printing pens, Office equipment, Massage health care, Beauty and fitness equipment, Medical equipment, Toys, Curling iron, Automotive automatic facilities.
What is a planetary gear motor?
Another significant advantage of planetary gear motors is their high efficiency. The gear system evenly distributes load among the planetary gears, resulting in lower wear and friction than other gear motor designs. This reduces energy losses and increases overall efficiency, making planetary gear motors a cost-effective choice for machinery and equipment that require continuous, reliable operation.
Planetary gear motors also provide excellent precision and control. Multiple gear stages in the motor provide different gear ratios, allowing a variety of speeds and torques. This versatility makes them suitable for applications requiring precise positioning and variable speed, such as robots or CNC machine tools.
Company Profile
A gear motor is a mechanical device consisting of an electric motor and a gearbox, differing from a DC motor for lower RPM and higher torque.
Micro Motors specializes in the manufacture of miniature gear motors, both with brushes and without brushes, and stepper motors.
A gear motor is a mechanical device consisting of an electric motor and a gearbox, differing from a DC motor for lower RPM and higher torque.
Micro Motors specializes in the manufacture of miniature gear motors, both with brushes and without brushes, and stepper motors.
we are DC gear motor manufacturer , my factory mainly produce and supply Micro DC planetary gear motor, Worm gear motor, Spur gear motor, Brushed motor , Brushless BLDC motor and so on , We have a professional engineering design team that can design motor performance parameters according to your product requirements.
