FT-49OGM500 DC Gear Motor for Automatic Feeder motor
short description:
Features
| Model number | Rated volt. | No load | Load | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA(max) | rpm | mA(max) | Kgf.cm | W | mA(min) | Kgf.cm | ||
| FT-49OGM5000063300-532K-3V | 3V | 3 | 50 | 2 | 110 | 2.6 | 0.05 | 140 | 7 |
| FT-49OGM5000031800-176K | 3V | 11 | 30 | 8 | 100 | 1 | 0.08 | 160 | 3 |
| FT-49OGM5000062100-105K | 6V | 20 | 50 | 12 | 120 | 1 | 0.12 | 160 | 2.5 |
| FT-49OGM5000064400-105K | 6V | 42 | 140 | 27.5 | 370 | 1.5 | 0.42 | 580 | 5 |
| FT-49OGM5000066000-176K | 6V | 34 | 300 | 22 | 720 | 3.8 | 0.86 | 1100 | 12 |
| FT-49OGM50066000-266K | 6V | 22 | 180 | 16 | 600 | 4.5 | 0.74 | 990 | 15 |
| FT-49OGM5000064000-530K | 6V | 8 | 80 | 5.6 | 200 | 5 | 0.29 | 450 | 19 |
| FT-49OGM5000123000-340K | 12V | 8 | 40 | 6 | 130 | 5 | 0.31 | 280 | 21 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
DC brushed reduction motors have a unique brush structure that enables seamless current transmission and commutation between the motor rotor and stator. This innovative design ensures the motor operates at maximum efficiency, delivering optimal power in every application.
One of the main advantages of this motor is its high power density. By utilizing brushes and brush structures, we are able to maximize the motor's power output within a compact size. This means our motors can deliver incredible power, making them ideal for the most demanding industrial and commercial applications.
Product Video
Company Profile
A gear motor is a mechanical device consisting of an electric motor and a gearbox, differing from a DC motor for lower RPM and higher torque.
Micro Motors specializes in the manufacture of miniature gear motors, both with brushes and without brushes, and stepper motors.
A gear motor is a mechanical device consisting of an electric motor and a gearbox, differing from a DC motor for lower RPM and higher torque.
Micro Motors specializes in the manufacture of miniature gear motors, both with brushes and without brushes, and stepper motors.
we are DC gear motor manufacturer , my factory mainly produce and supply Micro DC planetary gear motor, Worm gear motor, Spur gear motor, Brushed motor , Brushless BLDC motor and so on , We have a professional engineering design team that can design motor performance parameters according to your product requirements.
1.Q: Are you trading company or manufacturer?
A: We’re factory. We specialize in micro dc motor and dc gear motor for more than 20 years.
2.Q: What is the payment term for a new customer?
A: We can draw up an Ali Assurance Order Online for our new customer, which can pay online with Master Card, Visa, etc. Customer
also can pay with PayPal or TT etc.
3.Q: I can’t find a suitable motor on your website, can you customize the motor for me?
A: Yes, we can customize a suitable motor according to our customer’s requirements.
4.Q: Do you have certificates for the motors?
A: Yes, we have RoHS， CE, FCC, ISO, IATF16949 etc. If you have the other certificates requirement, we can apply it for you.
5.Q: How is your Quality Control?
A: We have professional checking staff on every production line process. After finishing the whole motor, we have the entire
quality machine to test the motor. Such as Hardness Tester, 2.5D Image Tester, Salt Spray Chamber, Life Tester, Temperature Test
Machine, and Noise tester etc.
