FT-25RGM370 Spur Gear Motor robot motor

short description:

  • Gear Motor Model : : Ft-25rgm370
  • Gear Box Diameter: : 25mm
  • Voltage : : 2~24V
  • Speed : : 2rpm~2000rpm
  • Torque: : Customization accepted
  • Product Detail

    Product Tags


    Its core description is to reduce the speed of the high-speed DC motor through the reduction mechanism and provide greater output torque to meet the needs of micro-equipment for low-speed and high-torque motion.


    Micro DC spur gear motor has the characteristics of small size, light weight and high transmission efficiency, and is widely used in various micro mechanical equipment. Here are some common application scenarios:

    Smart toys: Miniature DC spur gear motors can drive various actions of smart toys, such as turning, swinging, pushing, etc., bringing more diverse and interesting functions to toys.

    Robots: The miniaturization and high efficiency of miniature DC spur gear motors make them an important part of the robotics field. It can be used for robot joint actuation, hand motion and walking, etc.

    Smart home equipment: Micro DC spur gear motors can be used in smart home equipment, such as smart curtains, automatic door locks, smart electric doors, etc., to provide a convenient and comfortable home experience.

    Medical equipment: Miniature DC spur gear motors can be used in medical equipment, such as electric syringes, infusion pumps, surgical instruments, etc., to provide precise control and movement capabilities.

    About This Item

    A spur gear motor is a type of gear motor that uses spur gears to transfer and amplify power from the motor to the output shaft.  Spur gears are cylindrical gears with straight teeth that mesh together to transfer rotational motion.  Here are some key features and applications of spur gear motors.
