Ft-36PGM555 Planetary Gear Motor Brushless Motor

short description:

Technical Parameters

Voltage, output speed, torque, output shaft can be customized








  • Gear Motor Model : FT-36pgm555 Planetary Reduction Gear Motor
  • Gear Box Diameter : 36mm
  • Voltage : 2~24V
  • Speed : 2rpm~2000rpm
  • Torque: Customization accepted
  • Product Detail

    Product Tags

    Product Advantages

    SPECIFICATIONS
    The specifications aaccept customization
    Model number Rated volt. No load Load Stall
    Speed Current Speed Current Torque Power Current Torque
    rpm mA(max) rpm mA(max) Kgf.cm W mA(min) Kgf.cm
    FT-36PGM5550126000-5.2K 12V 1153 650 960 3000 1.2 11.8 10620 6.3
    FT-36PGM5550128000-14K 12V 571 900 465 3500 4 19.1 11550 19
    FT-36PGM5550126000-27K 12V 223 400 175 1600 4.2 7.5 5350 20
    FT-36PGM5550126000-51K 12V 117 680 85 2680 13 11.3 8350 60
    FT-36PGM5550126000-71K 12V 84 500 70 2400 14 10.1 8380 71
    FT-36PGM5550126000-99.5K 12V 60 450 48 2000 16 7.9 6300 78
    FT-36PGM5550124500-264K 12V 17 400 12 1500 28 3.4 2800 104
    FT-36PGM5550126000-721K 12V 8 400 6 3200 160 9.9 9000 630
    FT-36PGM5550246000-3.7K 24V 1621 500 1216 2000 1.5 18.7 8000 7.5
    FT-36PGM5550246000-5.2K 24V 1153 400 1016 1600 1.25 13 5380 8
    FT-36PGM5550124500-27K 24V 167 550 147 2000 6 9.1 6500 30
    FT-36PGM5550244500-71K 24V 63 220 48 1100 10 4.9 3700 50
    FT-36PGM5550243000-100K 24V 30 150 22 550 12 2.7 1180 55
    FT-36PGM5550246000-189K 24V 31 360 26 1800 41 10.9 4730 204
    FT-36PGM5550244500-264K 24V 17 220 14 1000 43 6.2 2700 221
    FT-36PGM5550244500-369K 24V 12 250 9 850 70 6.5 2500 280
    FT-36PGM5550246000-1367K 24V 4.3 450 3.2 2000 250 8.2 6500 1200
    Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in    1 mm≈0.039 in

    One of the primary advantages of planetary geared motors is their exceptional torque. With the ability to deliver high torque even in compact structures, these motors have garnered a reputation for their power and performance. Our 24V Planetary Gear Motor takes this characteristic to a whole new level, providing you with unparalleled strength to tackle your toughest tasks.

    1、High torque

    2、Compact structure

    3、High precision

    4、High efficiency

    5、Low noise

    6、Reliability

    7、Diversified choices

    Product Video

    Application

    DC Gear Motor Widely Used In Smart home appliances, Smart pet products ,Robots, Electronic locks, Public bicycle locks, Electric daily necessities, ATM machine , Electric glue guns, 3D printing pens,  Office equipment, Massage health care, Beauty and fitness equipment, Medical equipment, Toys,  Curling iron, Automotive automatic facilities.

    Company Profile

    FT-36PGM545-555-595-3650_12
    FT-36PGM545-555-595-3650_13
    FT-36PGM545-555-595-3650_11
    FT-36PGM545-555-595-3650_09

    About This Item

    Our motors are designed to address the limitations and challenges of traditional DC motors, delivering superior performance and durability.
    Due to their size and the use of metal brush commutators, the speed range of conventional DC motors is typically limited to 2 to 2000 rpm. However, faster speeds shorten motor life, leading to frequent replacements and increased maintenance costs. With our planetary gearmotors, these limitations are a thing of the past.

    One of the outstanding features of our motors is the use of a low-noise DC motor with an internal ring varistor. This clever addition effectively reduces electromagnetic interference to the environment, ensuring quiet, efficient operation. Whether you need a motor for a residential or commercial application, our planetary gear motors provide an unparalleled user experience.
