FT-42PGM775 High Efficiency Dc Planet Planetary Gear Motor
Features:
At the heart of the planetary gear motor lies its exceptional functionality. Built with precision and advanced engineering, this motor delivers a powerful torque while maintaining a compact and lightweight design. This enables its seamless integration into an extensive range of products, making it an indispensable tool for home automation and various industries.
Imagine your smart home appliances working effortlessly to enhance your daily life. The dc planetary gear motor provides the necessary drive to ensure the smooth operation of tasks such as automated vacuuming, seamlessly closing blinds, and even controlling robotic arms for intricate cooking processes. With this motor, Smart pet products can also come to life, making interactive toys more engaging and functional for your beloved furry friends.
| Model number | Rated volt. | No load | Load | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA(max) | rpm | mA(max) | Kgf.cm | W | mA(min) | Kgf.cm | ||
| FT-42PGM77501212000-3.7K | 12V | 3243 | 4700 | 2528 | 20000 | 3 | 77.8 | 43000 | 12 |
| FT-42PGM7750123500-3.7K | 12V | 945 | 600 | 772 | 3100 | 1.7 | 13.5 | 8000 | 8 |
| FT-42PGM7750127000-3.7K | 12V | 1891 | 1900 | 1544 | 8900 | 2.5 | 39.6 | 20000 | 10 |
| FT-42PGM7750126000-5K | 12V | 1200 | 1200 | 1087 | 6000 | 2.6 | 29 | 17430 | 13 |
| FT-42PGM7750128000-25K | 12V | 320 | 2000 | 226 | 7200 | 15 | 34.8 | 20500 | 62 |
| FT-42PGM7750127000-125K | 12V | 56 | 1100 | 47 | 7300 | 63 | 30.4 | 20900 | 313 |
| FT-42PGM7750126000-49K | 12V | 122 | 1250 | 97 | 4650 | 22.3 | 22.2 | 1730 | 122 |
| FT-42PGM7750126000-125K | 12V | 48 | 950 | 37 | 4200 | 52 | 19.7 | 12000 | 220 |
| FT-42PGM7750123600-125K | 12V | 28 | 550 | 23 | 2100 | 43 | 10.1 | 7100 | 222 |
| FT-42PGM7750246000-3.7K | 24V | 1621 | 700 | 1414 | 3800 | 2.3 | 33.4 | 12000 | 13.9 |
| FT-42PGM77502410000-13K | 24V | 769 | 1100 | 685 | 7400 | 9.9 | 69.6 | 27150 | 62 |
| FT-42PGM77502410000-14K | 24V | 730 | 860 | 626 | 5500 | 10.7 | 68.7 | 2500 | 64.6 |
| FT-42PGM7750248000-25K | 24V | 320 | 850 | 280 | 4000 | 15 | 43.1 | 14500 | 80 |
| FT-42PGM7750242100-49K | 24V | 42 | 170 | 32 | 700 | 13.5 | 4.4 | 1400 | 51 |
| FT-42PGM7750243000-49K | 24V | 61 | 200 | 53 | 1100 | 15.8 | 8.6 | 3500 | 93 |
| FT-42PGM7750242100-67K | 24V | 31 | 130 | 23 | 590 | 17 | 4 | 1420 | 75 |
| FT-42PGM7750247000-67K | 24V | 104 | 600 | 90 | 3600 | 32 | 29.6 | 13600 | 216 |
| FT-42PGM7750243600-125K | 24V | 28 | 300 | 24 | 1800 | 57 | 14 | 5400 | 300 |
| FT-42PGM7750244500-181K | 24V | 24.8 | 900 | 19 | 3030 | 92 | 17.9 | 6200 | 368 |
| FT-42PGM7750242000-336K | 24V | 6 | 150 | 4.7 | 500 | 57 | 2.7 | 1000 | 220 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
Application
Planetary geared motor/Geared brushless dc motor Widely Used In Smart home appliances, Smart pet products ,Robots, Electronic locks, Public bicycle locks, Electric daily necessities, ATM machine , Electric glue guns, 3D printing pens, Office equipment, Massage health care, Beauty and fitness equipment, Medical equipment, Toys, Curling iron, Automotive automatic facilities.
About This Item
The life of a DC motor mainly depends on the mechanical and chemical wear of the metal brushes and commutator. To meet this challenge, our planetary gear motors are specifically designed to provide an impressive run time of 300 to 500 hours at rated load and speed. This means you can rely on our motors to continue performing at their best for a long time without compromising their service life.
In addition to durability, our planetary gearmotors also offer outstanding performance. Its innovative gear system enhances torque and power transmission for smooth and efficient operation. Whether you need low-speed precision control or high-speed rotation, our motors can easily meet your specific requirements.
Company Profile
A gear motor is a mechanical device consisting of an electric motor and a gearbox, differing from a DC motor for lower RPM and higher torque.
Micro Motors specializes in the manufacture of miniature gear motors, both with brushes and without brushes, and stepper motors.
A gear motor is a mechanical device consisting of an electric motor and a gearbox, differing from a DC motor for lower RPM and higher torque.
Micro Motors specializes in the manufacture of miniature gear motors, both with brushes and without brushes, and stepper motors.
we are DC gear motor manufacturer , my factory mainly produce and supply Micro DC planetary gear motor, Worm gear motor, Spur gear motor, Brushed motor , Brushless BLDC motor and so on , We have a professional engineering design team that can design motor performance parameters according to your product requirements.
